Weidmuller 1906300250

The SAIL-M12GM12G-4-2.5U is a connecting line designed for sensor and actuator applications, featuring an M12 connector configuration with 4 poles. This cable measures 2.5 meters in length and is constructed with a PUR sheath, ensuring durability and flexibility in various environments.

It adheres to the IEC 61076-2-101 standard and achieves a protection rating of IP65, IP66, IP67, and IP68 when properly connected. The cable is rated for a voltage of 250 V and a current of 4 A, making it suitable for a wide range of industrial applications. The gold-plated contact surfaces enhance conductivity, while the cable's temperature range extends from -40 °C to +80 °C for stationary use and -25 °C to +80 °C when in motion.

With a core cross-section of 0.34 mm², the cable's outer diameter is 4.7 mm, and it is designed for high durability with a minimum bending radius of 5 times the cable diameter when stationary and 10 times when in motion. The cable exhibits resistance to oils and is compliant with various safety standards, including those concerning flame spread and hydrolysis resistance.

Overall, this model is suitable for applications requiring reliable connectivity in demanding conditions and is noted for its mechanical robustness and compliance with environmental regulations, including REACH SVHC.
