The TM160D is a 4-pole, 4d thermal-magnetic trip unit specifically designed for use with Compact NSX 160 circuit breakers. This product provides an optimal solution for all distribution applications due to its 160A rating.The TM160D embeds an adjustable thermal overload protection, which allows for customization based on specific application requirements. Additionally, it includes a fixed magnetic protection against short-circuits, ensuring reliable operation in the event of an unexpected surge in current.This trip unit is part of Schneider Electric's EcoStruxure Power architecture when used with PowerTag NSX and Compact NSX basic frame. This integration allows for seamless compatibility and enhanced system performance.

This is an accessory for Micrologic trip unit for Compact NSX and PowerPact multistandard devices. It is an external battery used for the local inspection and testing of Micrologic trip units. It enables to use Micrologic display screen and keypad even if the power supply to the Micrologic trip unit is interrupted. The pocket battery is connected to Micrologic test port with the trip unit connector (supplied with the pocket battery). Additionally, the pocket battery embeds a plastic screw-driver for the rotary switches settings and a flash light.

The Compact NSX100H is a high-performance, space-efficient circuit breaker designed to meet the demands of various applications. With a breaking capacity of 70kA rms at 415VAC and an operational voltage of 690VAC 50/60Hz, this product offers optimal performance and reliability.The Compact NSX100H is equipped with the advanced MicroLogic 2.2 trip unit, providing adjustable long time and short time protections, as well as a fixed instantaneous protection. This versatile circuit breaker comes in a compact size of 140mm x 161mm x 86mm, making it an ideal choice for applications where space is at a premium.The Compact NSX100H is compliant with international standards such as IEC 60947, CCC, EAC, and marine specifications. It is also part of Schneider Electric's EcoStruxure Power architecture, ensuring seamless integration into existing systems.

This standard motor mechanism is designed for use with Compact NSX 400/630 and PowerPact Multistandard L frame devices. It offers automatic device spring-charging, enhancing the circuit breaker's mechanical durability while ensuring easy and reliable opening or closing operations. The module provides a double insulation of the front face, keeping all indications visible and accessible. The control voltage ranges from 440VAC to 480VAC at 60Hz with a consumption less than 500VA. Padlocking of the device remains possible.

Dieses Produkt ist Teil der XAP-Reihe, einem Angebot von Metall-Steuerstationen für die Serien XB4 und XB5 mit Drucktasten Ø 22 mm. XAPK1501 handelt sich um ein leeres Gehäuse für den Not-Aus-Schalter mit einem vollständig gelben Formfaktor (RAL1004). Diese Version mit 1 Loch ermöglicht jede Art von Not-Halt mit oder ohne Typenschild. Legendenhalter in 2 Größen können in verschiedenen Positionen verwendet werden. Seine Abmessungen lassen einen bequemen Platz für die Verkabelung. Es ist möglich, den XAP mit der Online-Produktauswahl und dem Konfigurator von Harmony anzupassen. Dieses Produkt wurde mit metrischem Gewinde für die Verwendung mit ISO-Kabelverschraubungen standardisiert, um die IEC 62444 vollständig zu erfüllen. Es wird mit zwei M20-Löchern geliefert. Der Stromschlagschutz entspricht der Klasse I gemäß EN/IEC 61140 und der mechanische Schlagschutzstatus bis zu IK07 gemäß EN/IEC 62262. Dies ist ein Angebot aus Zinklegierung und die Abmessungen betragen 80 mm (Breite) x 80 mm (Höhe) x 77 mm (Tiefe) und es wiegt 0,600 kg. XAPK wurde für Erstausrüster (OEMs) entwickelt, die hohe Anforderungen an Anwendungen erfüllen, wie z. B. Materialtransport, Lebensmittel und Getränke, Windkraftanlagen, Bergbau, Mineralien und Metalle (MMM), Fahrzeuge usw. Dieses Gehäuse entspricht den Normen EN/IEC 60529 und EN/IEC 60947-5-1 und ist CE-, UL-, cULus- und EAC-zertifiziert. Vollständig angepasste Beschriftungsfelder sind verfügbar, um das Benutzeroberflächenerlebnis und die Ästhetik des Gehäuses zu verbessern. XAP ist so konzipiert, dass es sowohl in vertikaler als auch in horizontaler Position mit 4 Befestigungslöchern montiert werden kann. Der Formfaktor ermöglicht eine Kombination aus Einfachheit, Flexibilität bei der Anpassung und attraktivem Design für Maschinen. Es verbessert die Unterscheidung zwischen Standard- und Not-Aus-Leitstand.

The Schneider Electric TeSys GV4 Motor Circuit Breaker is a reliable solution designed to protect 3-phase motors with a rating of 22-37kW at 400V. This circuit breaker provides thermal magnetic protection and additional motor protection functions, ensuring optimal performance and safety.The TeSys GV4 Motor Circuit Breaker features a breaking capacity of Icu 100kA at 400V, allowing for start-stop control via toggle switch. It is equipped with Everlink BTR screw terminals for easy connection. The thermal protection can be adjusted by dials with a setting current Ir in the range of 40-80A and a selectable tripping class of 10 or 20.The circuit breaker also includes magnetic protection at 17 In, as well as additional protections with fixed pick-up and short time delay protection Isd at 13 Ir. It offers phase unbalance and loss protection, ground fault protection, and internal locations for auxiliary contact blocks (OF, SD) and voltage trip units (MN, MX).The TeSys GV4 Motor Circuit Breaker is multi-standard certified (IEC, UL, CSA, CCC, EAC, Marine, ATEX), and complies with Green Premium standards (RoHS/REACh).

This product is part of XAP range, an offer of metal control stations for XB4 and XB5 series of Ø 22mm pushbuttons. XAPD2503 is an empty enclosure with grey color (RAL7035). This version with 3 holes allows combination of XB4/XB5 functions in a small volume. Its dimension leaves a comfortable space for wiring. It is possible to customize the XAP with the Harmony online product selector and configurator. This product has been standardized with metric thread to be used with ISO cable glands to be fully compliant with the IEC 62444. It comes with two M20 holes. The electric shock protection is at class I conforming to EN/IEC 61140 and the mechanical shock protection level is up to IK07 conforming to EN/IEC 62262. This is a zinc alloy offer and the dimensions are 80mm (width) x 130mm (height) x 77mm (depth) and it weighs 0.815kg. XAPD is designed for Original Equipment Manufacturers (OEMs) that meets heavy duty application requirements such as material handling, food & beverage, wind turbines, Mining, Minerals and Metals (MMM), vehicles, etc. This enclosure complies with EN/IEC 60529 and EN/IEC 60947-5-1 and comes with CE, UL, cULus and EAC certification. Fully customized legend panel are available to improve interface experience and enclosure's aesthetic. XAP is designed to be mounted in both vertical and horizontal position with 4 fixing holes. The form factor allows a combination between simplicity, customization flexibility and attractive design for machines

This Micrologic 5.3 E (Energy) is a 4 poles 4d electronic trip unit used on Compact NSX 400/630 circuit breakers. This 400A rating electronic trip unit is an optimum choice for all standard and specific applications. It embeds adjustable long time protection against overloads. It provides also adjustable short-time protection and instantaneous protection against short-circuits. Micrologic 5.3 E indicates overloads with Alarm LEDs. The green Ready LED flashes if the circuit breaker is ready to trip. Micrologic 5.3 E is equipped with a display module that gives energy measurement and allows fine adjustment settings. This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and Compact NSX basic frame.

These accessories are crimp lugs for Compact NSX 100/160/250, EasyPact CVS 100/160/250 or FuPact INFB 100/160. These crimp lugs may be used for 185mm² copper cables. These crimp lugs are supplied with flexible interphase barriers for insulation reinforcement. They are sold by set of 4 parts.

The Micrologic 5.2 E is a high-performance electronic trip unit designed specifically for Schneider Electric's Compact NSX 250 circuit breakers. This 4-pole, 4d device offers a 250A rating and is equipped with advanced protection features such as adjustable long time protection against overloads, short-time protection, and instantaneous protection against short-circuits. The Micrologic 5.2 E also features an Alarm LED to indicate overloads and a Ready LED that flashes when the circuit breaker is ready to trip.The device comes with a display module that provides energy measurement and allows for fine adjustment settings. It is part of Schneider Electric's EcoStruxure Power architecture, making it compatible with PowerTag NSX and Compact NSX basic frame.

The Schneider Electric TeSys GV4 Motor Circuit Breaker is a robust and reliable solution designed to protect 3-phase motors with a rating of 0.25-0.75kW at 400V. This circuit breaker offers thermal magnetic protection, providing an additional layer of motor protection. It has a breaking capacity of Icu 50kA@400V and can be controlled by toggling the start-stop switch. The connection is facilitated through Everlink BTR screw terminals.The TeSys GV4 Motor Circuit Breaker comes with adjustable thermal protection settings, allowing for a current setting (Ir) in the range of 0.8-2A and selectable tripping classes of 10 or 20. The magnetic protection is set at 17 In. It also includes additional protections such as short time delay protection Isd at 13 Ir, phase unbalance and loss protection, and ground fault protection.This circuit breaker features internal locations for auxiliary contact blocks (OF, SD) and voltage trip units (MN, MX). It is multi-standard certified (IEC, UL, CSA, CCC, EAC, Marine, ATEX), and Green Premium compliant (RoHS/REACh).

Dieser Compact NSX400F ist ein kompletter 3P 3D-Festleistungsschalter, der zur Optimierung von Platz und Ausschaltvermögen entwickelt wurde. Es ist eine optimale Wahl für alle Standard- und spezifischen Anwendungen. Das Ausschaltvermögen (Icu) beträgt 36 kA rms bei 415 VAC 50/60 Hz. Die Betriebsspannung beträgt 690VAC 50/60Hz. In dieses Produkt ist eine elektronische Micrologic 2.3-Auslöseeinheit mit einer Nennleistung von 400 A eingebettet. Die Micrologic 2.3-Auslöseeinheit bietet einstellbaren Langzeit- und Kurzzeitschutz sowie einen festen Sofortschutz. Diese 3-polige Version (140 mm x 255 mm x 110 mm) wird mit einer Vielzahl von optionalen Funktionen und Zubehörteilen geliefert. Es entspricht den internationalen Standards (IEC 60947), CCC, EAC und Marinespezifikationen. Compact NSX400F ist Teil der EcoStruxure Power-Architektur von Schneider Electric.Hauptmerkmale:36 kA Ausschaltvermögen bei 415 VACMicroLogic 2.3-Auslöseeinheit mit 400 A NennleistungEinstellbarer Langzeit- und KurzzeitschutzFester sofortiger SchutzEinhaltung der Spezifikationen IEC 60947, CCC, EAC und SchifffahrtAnwendungen: Ideal für Standard- und spezifische Anwendungen, die Compact NSX400F wurde entwickelt, um den Platzbedarf und die Bremskapazität in verschiedenen Umgebungen zu optimieren, einschließlich industrieller, kommerzieller und maritimer Umgebungen.

This Compact NSX630H is a complete 3P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 70kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds an electronic Micrologic 2.3 trip unit, with 630A rating. Micrologic 2.3 trip unit provides adjustable long time and short time protections, and a fixed instantaneous protection. This 3 poles version (140mm x 255mm x 110mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. Compact NSX630H is part of Schneider Electric EcoStruxure Power architecture.

The Schneider Electric TeSys GV4 Motor Circuit Breaker is a robust solution designed to protect 3-phase motors ranging from 37-55kW at 400V. This circuit breaker offers thermal magnetic protection and additional motor protection functions, with a breaking capacity of Icu 25kA at 400V. It also provides start-stop control via a toggle switch, allowing for easy connection to bars or cables using lugs.The TeSys GV4 is equipped with thermal protection that can be adjusted by dials, offering a setting current Ir in the range of 65-115A and a selectable tripping class of either 10 or 20. It also features magnetic protection at 17 In, along with additional protections such as short time delay protection Isd at 13 Ir, phase unbalance and loss protection, and ground fault protection.This circuit breaker is multi-standard certified (IEC, UL, CSA, CCC, EAC, Marine, ATEX), and complies with Green Premium standards (RoHS/REACh). It also offers internal locations for additional auxiliary contact blocks (OF, SD) and voltage trip units (MN, MX).

This is an insulation accessory for 4 poles Compact NSX 400/630 or EasyPact CVS 400/630. This long terminal shield protects against direct contact with power circuit It is used for front connection with cables or insulated bars. It can be mounted upstream and downstream of fixed, plug-in or withdrawable devices. It allows to reach the clearance distance requested by IEC 60947-2 standard. The pitch is 52.5mm. It provides IP40 degree of protection and IK07 mechanical impact protection.

This is an insulation accessory for 4 poles Compact NSX 400/630 or EasyPact CVS 400/630. This short terminal shield protects against direct contact with power circuit. It can be mounted upstream and downstream of fixed, plug-in or withdrawable devices. It allows to reach the clearance distance requested by IEC 60947-2 standard. The pitch is 45mm. It provides IP40 degree of protection and IK07 mechanical impact protection.

These accessories are aluminium bare cable connectors for Compact NSX 100/160/250. These connectors can receive 6 copper or aluminium cables from 1.5mm² to 35mm². The connectors are screwed directly on the device terminals or right angle terminal extensions. The rated current is up to 250 A. They are sold by set of 3 parts.

The Compact NSX400/630 Motor Mechanism Module, model MT400/630, is designed to work seamlessly with Schneider Electric's Compact NSX 400/630 and PowerPact Multistandard L frame devices. This module provides an automatic spring-charging feature, enhancing the mechanical endurance of the circuit breaker while ensuring easy and reliable opening or closing operations.The module boasts a double insulation on its front face, keeping all indications visible and accessible at all times. It operates with a control voltage ranging from 110VDC to 130VDC, consuming less than 500W of power. The device remains padlockable, offering added security.

This product is a keylock adapter specifically designed for the motor mechanism padlocking system in Compact NSX 100/160/250. The adapter must be used with Ronis or Profalux keylocks (not supplied) to achieve the motor mechanism locking.

This is a 3 poles basic frame for Compact NSX100F. Compact NSX is designed to optimize space and breaking capacity for all standard and specific applications. This basic frame comes without trip unit, and is compatible with any type of trip unit ordered separately. The breaking capacity Icu is 36kA at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz (limited to 440VAC 50/60Hz if there is an earth-leakage protection). It can be equipped with a variety of optional functions and accessories. The dimensions are 105mm x 161mm x 86mm. It ensures compliance with international standards (IEC 60947), CCC, EAC and marine specifications. Compact NSX100F is part of Schneider Electric EcoStruxure Power architecture.
