MEAN WELL NDR-240-24

The MEAN WELL NDR-240-24 is a highly efficient, slim 240W DIN rail power supply designed for industrial applications. With a width of just 63mm, it saves valuable space inside cabinets. This power supply supports a full range AC input from 90VAC to 264VAC and complies with BS EN/EN61000-3-2, the European Union standard for harmonic current. The metal housing enhances power dissipation, and the unit operates with up to 90% efficiency, making it suitable for ambient temperatures from -20°C to 70°C under air convection.

The NDR-240-24 features constant current mode for overload protection, making it suitable for various inductive or capacitive applications. It includes comprehensive protection functions such as short circuit, overload, over voltage, and over temperature protection. Certified to UL508 and TUV BS EN/EN62368-1 standards, this power supply is a reliable choice for industrial control systems, semiconductor fabrication equipment, factory automation, and electro-mechanical applications.

Additional features include built-in active PFC function, cooling by free air convection, and the ability to be installed on DIN rail TS-35/7.5 or 15. The NDR-240-24 undergoes a 100% full load burn-in test and comes with a 3-year warranty, ensuring long-term reliability and performance.
