Schneider Electric

BDL36000S12

1 / 1

Descripción

Activo maduro

Country of Origin: MX
Part Number: BDL36000S12
Tariff Code: 8536200020
EAN: 39121601
UNSPSC: 39121601

Consigue plazos de pago de hasta 90 días de 500+ proveedores.
Descuentos de reventa de hasta el 40%!

Enviar solicitud de precio

1

Formas de pago:

Solicite un presupuesto y le enviaremos información sobre disponibilidad y precio.

Complementary

Mounting Mode: clip-on 35 x 15 mm symmetrical DIN rail) || by screws plate)
Height: 137 mm
Connection Pitch: 27 mm
Contact Position Indicator: yes
[Ue] Rated Operational Voltage: 600Y/347 V AC 50/60 Hz UL 489
Tightening Torque: 5-5 N.m 2.5-10 mm² || 9-9 N.m 16-95 mm²
Breaking Capacity Code: D
9 Mm Pitches: 9
Magnetic Tripping Current: 1320-1320 A
Number Of Slots: 1 auxiliary switch OF plug-in) || 1 voltage release MN or MX plug-in) || 1 alarm switch SD plug-in)
Electrical Connection: Everlink lug, line || Everlink lug, load
Magnetic Hold Current: 880 A
Control Type: toggle
Wire Stripping Length: 20 mm
Mechanical Durability: 15000 cycles IEC 947-1 Annex K ed 5.2
Short-Circuit Withstand: 25 kA 208Y/120 V UL 489 || 25 kA 240 V UL 489 || 18 kA 480Y/277 V UL 489 || 18 kA 480 V UL 489 || 14 kA 600 V UL 489
Electrical Durability: 10000 cycles IEC 947-1 Annex K ed 5.2 440 V In
Local Signalling: for presence of auxiliary contacts flag (green)
Poles Description: 3P
Quantity Per Set: set of 1
Line Rated Current: 125 A
Awg Gauge: AWG 6...AWG 2/0 fine stranded aluminium/copper || AWG 14...AWG 3/0 rigid or stranded aluminium/copper
Color: Gray RAL 7016)
Width: 81 mm
Depth: 89 mm

Offer Sustainability

Rohs Exemption Information: Yes
Mercury Free: Yes
Environmental Disclosure: ENVPEP1610005EN
Sustainable Offer Status: Green Premium product
Pvc Free: Yes
Reach Regulation: Reference contains Substances of Very High Concern above the threshold
California Proposition 65: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Weee: The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
China Rohs Regulation: Product out of China RoHS scope. Substance declaration for your information.
Circularity Profile: N/A
Eu Rohs Directive: Compliant with Exemptions
Halogen Content Performance: Halogen free product

Specifications

Product Or Component Type: automatic switch
Product Name: PowerPact B
Range: PowerPact
Device Application: distribution

Environment

Ambient Air Temperature For Operation: -25-70 °C
Standards: UL 489
Product Certifications: UL
Ambient Air Temperature For Storage: -50-85 °C
Quality Labels: CE
Operating Altitude: 6561.68 ft (2000 m) without derating || 5000 m with derating
