Schneider Electric XS7C4A1MPG13

The XS7 inductive proximity sensor offers reliable detection of metal objects without physical contact, thereby minimizing wear and enabling the safe detection of fragile or freshly painted items. This model has dimensions of 40 mm x 40 mm x 117 mm and is engineered for flush mounting in metal surfaces.

Constructed with a durable plastic enclosure, the sensor includes a plug-in turret head with five positions and a PG 13.5 cable entry. Operating on a two-wire system, it supports a supply voltage range from 24V to 240V AC or DC, with programmable normally open (NO) or normally closed (NC) output functions. It is imperative that this sensor is safeguarded by a 0.4A quick-blow fuse, part reference XUZE04, connected in series with the load.

With an IP67 rating conforming to IEC 60529, this sensor is suitable for challenging industrial conditions, demonstrating excellent resistance to dust and water. Its operational capabilities include a maximum switching frequency of 25 Hz for AC and 50 Hz for DC, ensuring high performance in various applications.

The XS7 features a nominal sensing distance of 15 mm and exhibits a maximum voltage drop of less than 5.5 V when closed. The product is equipped with LED indicators to denote power and output state, ensuring ease of monitoring during operation. It is certified to UL, CSA, and CCC standards, and operates effectively within a temperature range of -25 °C to 70 °C.
