Siemens
6AV2125-2GB03-0AX0
SIMATIC HMI KTP700 MOBILE, 7 , V13 SP1
- Termin płatności do 90 dni od 500+ dostawców.
- Rabaty na odsprzedaż do 40%!
€1,236.60
1
Metody płatności:
Łącznie 146 części w magazynie od 37 dostawców
Stan produktu:
Oferta z czasem realizacji przez producenta
Wysyłka:Na zapytanie
Najlepsza cena:
€1,658.32
Tak, możemy naprawić!
Współpracujemy z ponad 120 firmami naprawczymi w Europie, aby uzyskać najlepszą ofertę.
Czas realizacji:Na zapytanie
Możesz naprawić 6AV2125-2GB03-0AX0 za:
€862.00
Opis
AktywnyZgodny z RoHS
SIMATIC HMI KTP700 MOBILE, 7.0'' TFT DISPLAY, 800 X 480 PIXELS,16M COLOR, KEY AND TOUCH OPERATION, 8 FUNCTION KEYS, 1 X PROFINET/INDUSTRIAL ETHERNET INTERFACE; 1 X MULTIMEDIA CARD, 1 X USB, CONFIGURABLE FROM WINCC COMFORT V13 SP1Additional Information
- Part Number
- 6AV2125-2GB03-0AX0
- UPC
- 804766158063
- Tariff Code
- 8537109170
- Country of Origin
- DE
- ETIM
- Group Code : EG000024
- Group Description : PLC's
- Class Description : Mobile panel
- Class Code : EC001427
- Version : 7
Specifications
- Country of Origin
- DE
- Depth
- 89 mm
- Height
- 172 mm
- Width
- 248.4 mm
- With recipes
- true
- Type of display
- TFT
- Weight
- 1.2 kg/m²
- Screen diagonal
- 7 inch
- With touch screen
- true
- Supply voltage DC
- 19.2 V
- With colour display
- true
- Connection, pluggable
- true
- Number of system buttons
- 0
- Number of buttons with LED
- 8
- Number of password levels
- 50
- With message indication
- true
- Number of HW-interfaces USB
- 1
- Number of online languages
- 32
- Degree of protection (IP)
- IP65
- Number of pixels, vertical
- 480
- Operation temperature
- 0 °C
- Number of HW-interfaces other
- 0
- Number of interfaces PROFINET
- 1
- Number of HW-interfaces RS-232
- 0
- Number of HW-interfaces RS-422
- 0
- Number of HW-interfaces RS-485
- 0
- Number of pixels, horizontal
- 800
- Voltage type of supply voltage
- DC
- Number of HW-interfaces Wireless
- 0
- Number of HW-interfaces parallel
- 0
- Supporting protocol for MODBUS
- true
- Supporting protocol for TCP/IP
- true
- Number of HW-interfaces serial TTY
- 0
- Supporting protocol for EtherNet/IP
- true
- Supporting protocol for PROFINET IO
- true
- Number of colours of the display
- 16777216
- Number of function buttons, programmable
- 8
- Process default value (input) possible
- true
- Useful project memory/user memory
- 12000 kByte
- Number of HW-interfaces industrial Ethernet
- 1
- Process value representation (output) possible
- true
- With message system (incl. buffer and confirmation)
- true
- Max. height of fall (in accordance with IEC 60068-2-32)
- 1.2 m
