Phoenix Contact 1897526

The QC 0,5/15-ST-3,81 printed-circuit board connector is designed for reliable electrical connections in various applications. With a nominal cross section of 0.5 mm² and a rated voltage (III/2) of 200 V, this connector is suitable for a range of circuits. Its female contact design accommodates up to 15 potentials in a single row, making it efficient for compact layouts.

The connector employs a displacement connection method and features a pitch of 3.81 mm. It has a total of 15 connections, each with one solder pin, facilitating straightforward PCB integration. The locking mechanism is absent, allowing for easy assembly and disassembly, while the mounting type is also designed to be without additional hardware.

Constructed with a tin contact surface, this connector ensures durability and conductivity. The housing is made from PA insulating material, rated for a maximum operating temperature of 100 °C, with a storage and transport temperature range of -40 °C to 70 °C. Additionally, it meets various compliance standards, including WEEE/RoHS, and is free of whiskers as per IEC 60068-2-82/JEDEC JESD 201.
