Phoenix Contact 3043093

The plug, designated as SP 2,5/ 1-R GNYE, operates at a nominal voltage of 500 V and supports a maximum current of 24 A. It incorporates a spring-cage connection method, ensuring reliable connectivity. The rated cross section is 2.5 mm², with an allowable range of conductor cross-sections from 0.08 mm² to 4 mm², accommodating various installation requirements.

This component is characterized by its green-yellow coloration and a compact design, measuring 5.2 mm in width, 15.8 mm in height, and 39 mm in depth. Designed for operational flexibility, the plug can function in ambient temperatures as low as -60 °C and up to 70 °C, while maintaining performance in conditions of 20% to 90% humidity.

Compliance with industry standards is assured, as this plug adheres to IEC 61984, enabling connection and disconnection under load or voltage when utilized as intended. Additionally, it meets several fire protection and flammability ratings, including UL 94 V0 and various classifications under DIN EN 45545-2, ensuring safety for rail vehicle applications.
