Schneider Electric LZ8H6X53BD
TeSys Hybrid Reverse Starter, 3-Phase, 500VAC, 3kW at 400V, 24VDC, Spring Terminal
Product Description
The TeSys Hybrid ultra compact reverse safety starter is designed for the control and protection of 3-phase motors, with a maximum capacity of 3kW at 400V (3HP at 480V). This hybrid technology provides an ultra-compact design, measuring just 22.5mm in width, while also offering extended electrical durability up to 30 million cycles. The starter offers control for two directions of rotation and adjustable motor current ranging from 1.5A to 6.5A. It features class 10A thermal overload protection with auto/manual/remote reset, phase loss and phase unbalanced protection, stall and jam motor protection.
The TeSys Hybrid reverse safety starter is supplied with a 24V DC power source and includes logic inputs for forward/reverse motor direction and remote reset after thermal tripping. It also features a 1C/O contact relay for fault indication and an LED status on the front face for indication of tripping and motor running.
This starter is equipped with an integrated Safe Torq Off (STO) function, certified to SIL3 level according IEC61508-1 and PLe level according ISO13849-1. It can be easily integrated into safety chain applications. The DIN rail mounting design allows for easy installation, while the spring terminals provide reliable connections for control and power.
The TeSys Hybrid reverse safety starter is designed to operate in ambient temperatures ranging from -25°C to 70°C without derating. It has been certified to multiple standards (IEC, UL, CCC) and complies with Green...
Need more information?
Offer details
- Offer from:
Trusted supplier — Romania, member since 2023, 1–4 employees - Availability:
- On requestLead time: 21 days
- Warranty:
- Not specified
- Condition:
- New Surplus
Specifications
- Brand
- Schneider Electric
- Reset
- manual || electrical reset
- Standards
- UL 60947-4-1 || IEC 60947-4-2
- Mounting Support
- DIN rail
- Pollution Degree
- 2
- [Uimp] Rated Impulse Withstand Voltage
- 6 kV
- Connections - Terminals
- spring clamp terminals 1 0.2-2.5 mm² rigid || spring clamp terminals 1 0.25-2.5 mm² flexible - with cable end || spring clamp terminals 1 0.2-2.5 mm² flexible - without cable end
Available Offers
(3)| Condition | Availability | Supplier | Warranty | Action | |
|---|---|---|---|---|---|
 | Condition New Surplus | Availability On requestLead time: 21 days | SupplierRomaniaTrusted supplier — member since 2023, 1–4 employees | Warranty Not specified | |
| Condition New Factory Sealed | Availability On requestLead time to be confirmed | Supplier GermanyTrusted supplier — member since 2024 | Warranty Not specified | |
| Condition New Factory Sealed | Availability On requestLead time to be confirmed | Supplier ItalyTrusted supplier — member since 2021, 10–19 employees | Warranty 12 months |
Offer with manufacturer lead time
Directly from the manufacturer - with a confirmed, predictable, and fully transparent delivery time.
Documents
Data Sheet
Datasheet for Schneider Electric LZ8H6X53BD, including specifications and features.
CAD Models
3D CAD model and technical drawings, ready for your design software.
Product data updated: 22-08-2026
