Schneider Electric TSXDEZ12D2
Modicon TSX Micro Discrete Input Module
Product Description
The Modicon TSX Micro TSXDEZ12D2 serves as a discrete input module within the Modicon TSX Micro automation platform. It includes 12 screw terminal block inputs, functioning effectively with a rated supply voltage of 24V DC. The module accommodates both PNP and NPN configurations for 2/3-wire proximity sensors, thereby facilitating diverse sensor integration.
With a positive current consumption of 123mA and a negative current consumption of 107mA, the TSXDEZ12D2 is designed for reliability and precision. It guarantees input states with a current of at least 2.5mA for state 1 and a maximum of 1.5mA for state 0, while maintaining an input impedance of 2.4 Ohm. The response time ranges between 0.1 to 7.5 ms for transitions between states.
This module adheres to IEC 1131-2 Type 1 standards, ensuring compliance with industrial regulations. It features an isolation voltage of 1500V AC, providing essential protection for connected systems. Designed for applications in infrastructure, machinery, and manufacturing control, the TSXDEZ12D2 remains a dependable component in automation despite being discontinued on December 31, 2019, and scheduled for end-of-service on December 31, 2027.
Need more information?
Offer details
- Offer from:
Trusted supplier — Romania, member since 2023, 1–4 employees - Availability:
- On requestLead time: 21 days
- Warranty:
- Not specified
- Condition:
- New Surplus
Specifications
- Brand
- Schneider Electric
- Range of product
- Modicon TSX Micro automation platform
- Product or component type
- Discrete input module
- Discrete input number
- 12 screw terminal block
- Discrete input voltage
- 24 V DC, discrete input logic: positive or negative 19...30 V
- Discrete input current
- 9 mA
- Commercial reference
- TSXDEZ12D2
Available Offers
(9)| Condition | Availability | Supplier | Warranty | Action | |
|---|---|---|---|---|---|
| Condition New Surplus | Availability On requestLead time: 21 days | SupplierRomaniaTrusted supplier — member since 2023, 1–4 employees | Warranty Not specified | |
 | Condition Used | Availability 1 pc. Updated at: 19-09-2026In-Stock | Supplier SwitzerlandTrusted supplier — member since 2023 | Warranty 3 months | |
 | Condition Used | Availability 2 pcs. Updated at: 18-09-2026In-Stock | Supplier GermanyTrusted supplier — member since 2025, 5–9 employees | Warranty 6 months | |
| Condition Used | Availability On requestLead time to be confirmed | Supplier FranceTrusted supplier — member since 2021 | Warranty Not specified | |
 | Condition Used | Availability 1 pc. Updated at: 18-09-2026In-Stock | SupplierGermanyTrusted supplier — member since 2025, 5–9 employees | Warranty 6 months | |
| Condition Used | Availability 5 pcs. Updated at: 18-09-2026In-Stock | Supplier PolandTrusted supplier — member since 2022, 1–4 employees | Warranty 3 months |
Documents
Data Sheet
Datasheet for Schneider Electric TSXDEZ12D2, including specifications and features.
CAD Models
3D CAD model and technical drawings, ready for your design software.
Product data updated: 22-08-2026
