Weidmuller 1001980000
LL 5.08/17/90 3.2SN OR BX
Product Description
This printed circuit board terminal is designed with a pitch of 5.08 mm and accommodates 17 poles with a 90° angle for wire connection. The solder pin length measures 3.2 mm, and the connection is established via a clamping yoke. The maximum clamping range is 6 mm², making it suitable for various applications.
Rated data according to UL 1059 indicates a rated voltage of 300 V and a rated current of 20 A for Use Group B. For Use Group D, the rated current is 10 A. These terminals meet the requirements of standards such as IEC 60664-1 and IEC 61984, with notable ratings for surge voltage and impulse voltage classes.
The insulating material is Wemid (PA), colored orange, with a Comparative Tracking Index (CTI) of ≥ 600. The terminal is rated for operating temperatures from -50°C to 120°C and has a UL 94 flammability rating of V-0. Furthermore, it complies with multiple approvals including CSA and EAC.
