Weidmuller 1146790000
PCB Plug-In Connector SL 5.08HC/05/90 3.2SN OR BX
Product Description
The PCB plug-in connector features a male header with an open side and is specifically designed for through-hole technology (THT) solder connection. With a pitch of 5.08 mm and a total of five poles, this connector is engineered to accommodate various applications while ensuring reliable connectivity.
Notable specifications include a rated current of 18.5 A for use group B and 10 A for use group D according to UL 1059, with a rated voltage of 300 V in both use groups. This connector meets international standards including IEC 60664-1 and IEC 61984, offering a maximum rated voltage of 400 V under pollution degree II/2.
Constructed from PA GF material with an orange color finish, the connector exhibits a Comparative Tracking Index (CTI) of ≥ 550 and a flammability rating of UL 94 V-0. Its operational temperature range spans from -50°C to 100°C, ensuring functionality in diverse environmental conditions.
The dimensions of the connector include a width of 25.4 mm, height of 11.7 mm, and depth of 12 mm, weighing 1.82 g. It is packaged in a box for ease of handling and storage.
For further assurance, it holds multiple approvals, including cURus and EAC, and complies with RoHS directives.
Need more information?
Offer details
- Offer from:
Trusted supplier — Italy, member since 2021, 10–19 employees - Availability:
- On requestLead time to be confirmed
- Warranty:
- 12 months
- Condition:
- New Factory Sealed
Specifications
- Brand
- Weidmuller
- Institute (cURus)
- cURus
- Certificate No. (cURus)
- E60693
- Rated voltage (Use group B / UL 1059)
- 300 V
- Rated voltage (Use group D / UL 1059)
- 300 V
- Rated current (Use group B / UL 1059)
- 18.5 A
- Rated current (Use group D / UL 1059)
- 10 A
