Weidmuller 1147430000
SL 5.08HC/06/180B 3.2SN OR BX
Product Description
The SL 5.08HC/06/180B 3.2SN OR BX is a PCB plug-in connector designed for male header applications. This component includes dovetails for securing blocks and features a 180° outgoing elbow. The connector has a pitch of 5.08 mm and accommodates 6 poles, each with a solder pin length of 3.2 mm, ensuring reliable connectivity.
With a rated voltage of 300 V and a current rating of up to 18.5 A, this connector is suitable for various industrial applications. It has been tested according to IEC standards 60664-1 and 61984, offering robust performance in demanding environments. The device is constructed from PA GF insulating material, with a distinctive orange color, and exhibits a high Comparative Tracking Index (CTI) of ≥ 550.
Operating temperatures range from -50 °C to 100 °C, making it versatile for different settings. The connector’s design supports a maximum plugging force of 10 N and a pulling force of 7.5 N per pole, ensuring durable and secure connections. Additionally, it conforms to cURus, EAC, and KEMAKEUR approvals, reinforcing its compliance with international safety and quality standards.
Need more information?
Offer details
- Offer from:
Trusted supplier — Italy, member since 2021, 10–19 employees - Availability:
- On requestLead time to be confirmed
- Warranty:
- 12 months
- Condition:
- New Factory Sealed
Specifications
- Brand
- Weidmuller
- Institute (cURus)
- cURus
- Certificate No. (cURus)
- E60693
- Rated voltage (Use group B / UL 1059)
- 300 V
- Rated voltage (Use group D / UL 1059)
- 300 V
- Rated current (Use group B / UL 1059)
- 18.5 A
- Rated current (Use group D / UL 1059)
- 10 A
Available Offers
(1)| Condition | Availability | Supplier | Warranty | Action | |
|---|---|---|---|---|---|
 | Condition New Factory Sealed | Availability On requestLead time to be confirmed | SupplierItalyTrusted supplier — member since 2021, 10–19 employees | Warranty 12 months |
Offer with manufacturer lead time
Directly from the manufacturer - with a confirmed, predictable, and fully transparent delivery time.
Documents
Data Sheet
Datasheet for Weidmuller 1147430000, including specifications and features.
CAD Models
3D CAD model and technical drawings, ready for your design software.
Product data updated: 19-09-2026
