Weidmuller 1148200000
5.08 mm Male Header Connector, 7 Poles, 90° Angle, 3.2 mm Solder Pin Length
Product Description
This PCB plug-in connector is designed as a male header with dovetails for securing blocks. It supports a through-hole (THT) solder connection with a pin pitch of 5.08 mm and an angle of 90°. The solder pin length measures 3.2 mm and is tinned for enhanced conductivity.
The connector is rated for a maximum voltage of 300 V and a rated current of up to 18.5 A, as per UL 1059 standards. It complies with multiple approval standards including cURus and EAC. Its dimensions are 37.32 mm in width, 11.7 mm in height, and 12 mm in depth, with a net weight of 2.19 g.
Constructed from PA GF insulating material in orange, it features a Comparative Tracking Index (CTI) of ≥ 550 and an insulation strength of ≥ 108 Ω. The operating temperature ranges from -50 °C to 100 °C, making it suitable for various environments. The product also adheres to IEC standards and has a UL 94 flammability rating of V-0.
Designed for use in the OMNIMATE Signal product family, this connector allows for a maximum of 25 plugging cycles and has a pulling force of 7.5 N per pole. It is packaged in a box with dimensions 40 mm x 120 mm x 170 mm.
