Weidmuller 1154880000

The SL 5.08HC/12/90B 3.2SN OR BX is a specialized PCB plug-in connector designed for reliable board connectivity. With a 5.08 mm pitch and a total of 12 poles, this connector is optimized for THT solder connections, facilitating straightforward integration onto printed circuit boards.

Rated for a maximum voltage of 300 V and a current of 18.5 A as per UL 1059 standards, this connector is suitable for various applications requiring robust electrical performance. Its design includes dovetails for secure block fixing, enhancing mechanical stability.

Constructed from PA GF insulating material, the connector exhibits a high comparative tracking index (CTI) of ≥ 550, ensuring superior insulation properties. It operates effectively within a temperature range of -50 °C to 100 °C, making it suitable for diverse environmental conditions.

Approval certifications include cURus, EAC, and KEMAKEUR, confirming its compliance with international standards. The package dimensions are 35 mm in length, 115 mm in width, and 165 mm in height, with a net weight of 4.66 g. This connector also features a distinctive orange color, making it easily identifiable in applications.

Overall, the SL 5.08HC/12/90B 3.2SN OR BX combines technical efficiency with reliable performance, making it an essential component in electronic assembly.
