Weidmuller 1154890000
5.08 mm PCB Plug-in Connector, Male Header, 13 Poles, 90°
Product Description
This PCB plug-in connector features a male header with 13 poles arranged at a 90° angle, designed for THT solder connections. The solder pin length is 3.2 mm, and the connector is tinned and colored orange. The product belongs to the OMNIMATE Signal series, specifically the BL/SL 5.08 series.
With a rated voltage of 300 V and a rated current of 18.5 A under group B conditions according to UL 1059, this connector is suitable for a variety of applications. The component is constructed from PA GF insulating material with a high Comparative Tracking Index (CTI) of ≥ 550. It operates effectively within a temperature range of -50 °C to 100 °C and has a storage temperature range of -25 °C to 55 °C, with a maximum relative humidity of 80% during storage.
In terms of dimensions, the connector has a width of 67.8 mm, a height of 11.7 mm, and a depth of 12 mm, with a net weight of 4.98 g. It is packaged in a box, with specific packaging dimensions of 35 mm in length, 115 mm in width, and 170 mm in height. The component is approved by cURus, EAC, and KEMAKEUR, and conforms to ROHS standards.
Need more information?
Offer details
- Offer from:
Trusted supplier — Italy, member since 2021, 10–19 employees - Availability:
- On requestLead time to be confirmed
- Warranty:
- 12 months
- Condition:
- New Factory Sealed
Specifications
- Brand
- Weidmuller
- Institute (cURus)
- cURus
- Certificate No. (cURus)
- E60693
- Rated voltage (Use group B / UL 1059)
- 300 V
- Rated voltage (Use group D / UL 1059)
- 300 V
- Rated current (Use group B / UL 1059)
- 18.5 A
- Rated current (Use group D / UL 1059)
- 10 A
Available Offers
(1)| Condition | Availability | Supplier | Warranty | Action | |
|---|---|---|---|---|---|
 | Condition New Factory Sealed | Availability On requestLead time to be confirmed | SupplierItalyTrusted supplier — member since 2021, 10–19 employees | Warranty 12 months |
Offer with manufacturer lead time
Directly from the manufacturer - with a confirmed, predictable, and fully transparent delivery time.
Documents
Data Sheet
Datasheet for Weidmuller 1154890000, including specifications and features.
CAD Models
3D CAD model and technical drawings, ready for your design software.
