Weidmuller 1234470000
LM 5.00/24/180 3.5SN OR BX
Product Description
The LM 5.00/24/180 3.5SN OR BX terminal block is designed for use in various electrical applications. It features a solder pin length of 3.5 mm and utilizes a clamping yoke connection. This model supports a maximum clamping range of 2.5 mm², accommodating wire sizes from AWG 24 to AWG 14.
With an overall width of 120.55 mm and a height of 13.5 mm, this terminal block is compact and efficient. It is rated for a voltage of up to 300 V according to UL 1059 and can handle a current of 15 A for Group B. The terminal block has been tested to IEC standards, boasting rated impulse voltages of 4 kV under specific conditions.
Constructed from Wemid (PA) insulating material, it features an orange color and achieves a Comparative Tracking Index (CTI) of ≥ 600. The design includes multiple approvals, including CSA and cURus, ensuring compliance with international standards. The LM series is characterized by a 180° conductor outlet direction and a single-row configuration with a maximum of 24 adjacent poles.
Need more information?
Offer details
- Offer from:
Trusted supplier — Italy, member since 2021, 10–19 employees - Availability:
- On requestLead time to be confirmed
- Warranty:
- 12 months
- Condition:
- New Factory Sealed
Specifications
- Brand
- Weidmuller
- Institute (cURus)
- cURus
- Certificate No. (cURus)
- E60693
- Rated voltage (Use group B / UL 1059)
- 300 V
- Rated voltage (Use group D / UL 1059)
- 300 V
- Rated current (Use group B / UL 1059)
- 15 A
- Rated current (Use group D / UL 1059)
- 10 A
Available Offers
(1)| Condition | Availability | Supplier | Warranty | Action | |
|---|---|---|---|---|---|
 | Condition New Factory Sealed | Availability On requestLead time to be confirmed | SupplierItalyTrusted supplier — member since 2021, 10–19 employees | Warranty 12 months |
Offer with manufacturer lead time
Directly from the manufacturer - with a confirmed, predictable, and fully transparent delivery time.
Documents
Data Sheet
Datasheet for Weidmuller 1234470000, including specifications and features.
CAD Models
3D CAD model and technical drawings, ready for your design software.
