Weidmuller 1543330000
SVD 7.62HP/10/270G 3.2SN BK BX
Product Description
This PCB plug-in connector is designed for reliable connections with a male header configuration and a closed side. It features a THT solder connection, specifically designed with a 7.62 mm pitch and accommodates 10 poles. With a solder pin length of 3.2 mm, this connector ensures effective electrical contact.
The device is compliant with UL 1059 standards, with a rated voltage of up to 600 V and a rated current of 30 A, making it suitable for various applications where high voltage and current ratings are required. It is constructed from durable materials, including a PA GF insulating material with a flammability rating of V-0, ensuring safety and reliability in operation.
Approved by cURus, this connector also features a significant insulation strength of ≥ 108 Ω and a Comparative Tracking Index (CTI) of ≥ 600. The operational temperature range spans from -50 °C to 120 °C, allowing it to function effectively in diverse environmental conditions.
Notably, the connector supports touch-safe protection according to DIN VDE standards, ensuring safety during installation and operation. The product family it belongs to is the OMNIMATE Power series BV/SV 7.62HP, which is recognized for its robust design tailored for board connections.
