Weidmuller 1571260000

The connector is designed for PCB mounting with a 5.00 mm pitch and offers a male header configuration with 16 poles. It is suitable for THT solder connections, with a solder pin length of 3.2 mm. Compliance with safety standards is ensured, as indicated by its certifications including CSA, EAC, and UR with reference certificate number E60693.

Constructed from PBT insulating material in an orange color, this connector features a Comparative Tracking Index (CTI) of ≥ 200 and an insulation strength of ≥ 108 Ω. The rated voltage for use in pollution degree II/2 is 400 V, while for pollution degree III/2, it is 320 V. The connector can withstand rated impulse voltages of up to 4 kV, making it suitable for demanding applications.

With dimensions of 80 mm in width, 11.6 mm in height, and 12 mm in depth, it has a net weight of 4.97 g. The operating temperature range is from -50 °C to 100 °C, and it can handle a storage temperature range from -25 °C to 55 °C. The product family is categorized under the OMNIMATE Signal series, and the packaging is in a box with dimensions of 30 mm x 135 mm x 195 mm.
