Weidmuller 1726430000
PCB Plug-in Connector SLD 5.08V/34/90B 3.2 SN OR BX
Product Description
The SLD 5.08V/34/90B 3.2 SN OR BX is designed for reliable board connections with a pitch of 5.08 mm and 34 poles. It utilizes THT solder connections and features a solder pin length of 3.2 mm. The male header is equipped with dovetails for secure block mounting.
Constructed from PBT insulating material, it is orange in color and meets stringent safety standards, including UL 1059, IEC 60664-1, and IEC 61984. The connector supports a rated voltage of 300 V and a rated current of 10 A under both UL and CSA approvals. It has a maximum operating temperature of 100 °C and can tolerate storage conditions between -25 °C and 55 °C.
This component is classified under ETIM 6.0 (EC002637) and is suitable for a variety of applications that require reliable electrical connections. The connector is designed for a maximum of 25 plugging cycles and is compliant with IPC standards. It can accommodate a pin series quantity of 2 and features a minimum creepage distance according to application standards.
Need more information?
Offer details
- Offer from:
Trusted supplier — Italy, member since 2021, 10–19 employees - Availability:
- On requestLead time to be confirmed
- Warranty:
- 12 months
- Condition:
- New Factory Sealed
Specifications
- Brand
- Weidmuller
- Institute (UR)
- UR
- Certificate No. (UR)
- E60693
- Rated voltage (Use group B / UL 1059)
- 300 V
- Rated voltage (Use group D / UL 1059)
- 300 V
- Rated current (Use group B / UL 1059)
- 10 A
- Rated current (Use group D / UL 1059)
- 10 A
Available Offers
(1)| Condition | Availability | Supplier | Warranty | Action | |
|---|---|---|---|---|---|
 | Condition New Factory Sealed | Availability On requestLead time to be confirmed | SupplierItalyTrusted supplier — member since 2021, 10–19 employees | Warranty 12 months |
Offer with manufacturer lead time
Directly from the manufacturer - with a confirmed, predictable, and fully transparent delivery time.
Documents
Data Sheet
Datasheet for Weidmuller 1726430000, including specifications and features.
CAD Models
3D CAD model and technical drawings, ready for your design software.
