Weidmuller 1813630000

The 10.16mm male header connector is engineered for board connections with a pitch of 10.16 mm and a 90° outgoing elbow. It accommodates 8 poles, each equipped with 3 solder pins measuring 3.5 mm in length. This connector is suitable for THT solder connections and comes in a black color, adhering to the UL 1059 standards, with a rated voltage of 300 V for use groups B and C, and 600 V for use group D.

Constructed from PBT GF insulating material with a flame rating of UL 94 V-0, this component demonstrates a high level of durability and safety. It operates effectively across a temperature range of -50°C to 120°C and maintains insulation resistance exceeding 108 Ω. The connector also features a comparative tracking index (CTI) of ≥ 200, ensuring robust performance in various environments.

Additional specifications include a minimum clearance distance of 8.9 mm and a creepage distance of 10.5 mm, important for compliance with safety standards. The connector is packaged in a box with dimensions of 70 mm x 125 mm x 195 mm. This product is part of the OMNIMATE Power series BU/SU 10.16HP, enhancing its compatibility within a range of applications.
