Weidmuller 1953480000
LMZF 10/3/135 3.5OR
Product Description
The LMZF 10/3/135 3.5OR is a printed circuit board terminal designed for efficient connectivity in electronic applications. It features a tension-clamp connection accommodating a maximum clamping range of 2.5 mm² and is configured for three poles at a 135° angle, ensuring optimal space management on the PCB.
With a width of 32.5 mm and a height of 16.48 mm, this terminal supports a rated voltage of 300 V in use group B and C, and 150 V in use group D, along with a rated current of 15 A for groups B and C. The unit meets IEC standards and has a high impulse voltage rating of 8 kV, making it suitable for various industrial environments.
The insulating material, Wemid (PA), provides durability with a flammability rating of UL 94 V-0. This terminal operates within a temperature range of -50 °C to 120 °C, and is packaged in a protective box for safe storage and transport. Compliance with standards such as cURus and EAC ensures reliability in its applications.
Need more information?
Offer details
- Offer from:
Trusted supplier — Italy, member since 2021, 10–19 employees - Availability:
- On requestLead time to be confirmed
- Warranty:
- 12 months
- Condition:
- New Factory Sealed
Specifications
- Brand
- Weidmuller
- Institute (cURus)
- cURus
- Certificate No. (cURus)
- E60693
- Rated voltage (Use group B / UL 1059)
- 300 V
- Rated voltage (Use group C / UL 1059)
- 150 V
- Rated voltage (Use group D / UL 1059)
- 300 V
- Rated current (Use group B / UL 1059)
- 15 A
Available Offers
(1)| Condition | Availability | Supplier | Warranty | Action | |
|---|---|---|---|---|---|
 | Condition New Factory Sealed | Availability On requestLead time to be confirmed | SupplierItalyTrusted supplier — member since 2021, 10–19 employees | Warranty 12 months |
Offer with manufacturer lead time
Directly from the manufacturer - with a confirmed, predictable, and fully transparent delivery time.
Documents
Data Sheet
Datasheet for Weidmuller 1953480000, including specifications and features.
CAD Models
3D CAD model and technical drawings, ready for your design software.
Product data updated: 19-09-2026
