Weidmuller 2014420000
Printed Circuit Board Terminal 12.70 mm 5 Poles 90°
Product Description
The printed circuit board terminal is designed with a width of 12.70 mm and allows for a maximum clamping range of 16 mm², supporting a variety of conductor sizes. It features a 90° outlet direction and utilizes a clamping yoke connection for secure wire attachment. The solder pin is 5 mm long, ensuring compatibility with standard PCB mounting methods.
Rated for a maximum current of 65 A and a voltage of 600 V, this terminal is compliant with UL 1059 standards, making it suitable for industrial applications. The operating temperature ranges from -50°C to 120°C, providing versatility across various environments. The insulating material used is Wemid (PA), colored black, and exhibits a high comparative tracking index (CTI) of ≥ 600, ensuring durability and reliability.
Additional certifications include cURus compliance, making it ideal for a range of electrical installations. The terminal's construction allows for efficient heat dissipation, and its compact design optimizes space on the PCB. The terminal is packaged in a box for secure transport.
For detailed specifications, refer to the approval certificates and technical documentation associated with this product.
Need more information?
Offer details
- Offer from:
Trusted supplier — Italy, member since 2021, 10–19 employees - Availability:
- On requestLead time to be confirmed
- Warranty:
- 12 months
- Condition:
- New Factory Sealed
Specifications
- Brand
- Weidmuller
- Institute (cURus)
- cURus
- Certificate No. (cURus)
- E60693
- Rated voltage (Use group B / UL 1059)
- 600 V
- Rated voltage (Use group C / UL 1059)
- 600 V
- Rated current (Use group B / UL 1059)
- 65 A
- Rated current (Use group C / UL 1059)
- 65 A
Available Offers
(1)| Condition | Availability | Supplier | Warranty | Action | |
|---|---|---|---|---|---|
 | Condition New Factory Sealed | Availability On requestLead time to be confirmed | SupplierItalyTrusted supplier — member since 2021, 10–19 employees | Warranty 12 months |
Offer with manufacturer lead time
Directly from the manufacturer - with a confirmed, predictable, and fully transparent delivery time.
Documents
Data Sheet
Datasheet for Weidmuller 2014420000, including specifications and features.
CAD Models
3D CAD model and technical drawings, ready for your design software.
Product data updated: 19-09-2026
