Weidmuller 2529680000
SV-SMT 7.62HP/05/270MSF3 SC/8 2.6SN BX
Product Description
The SV-SMT 7.62HP/05/270MSF3 SC/8 2.6SN BX is a PCB plug-in connector with a male header and a closed side, designed for board mounting via THT/THR solder connections. It supports a pitch of 7.62 mm and accommodates 5 poles, each with a solder pin length of 2.6 mm.
This connector is compliant with various standards, including IEC 60664-1 and IEC 61984, with a rated voltage for surge voltage classes II/2 of 1,000 V and III/2 of 630 V. The rated current is up to 41 A at 20°C across its poles. It features a minimum clearance distance of 6.9 mm and a creepage distance of 9.6 mm, ensuring safety and reliability in various applications.
Constructed from PA GF HT insulating material, the connector is black in color and exhibits a Comparative Tracking Index (CTI) of ≥ 600. It operates efficiently within a temperature range of -50°C to 130°C, making it suitable for diverse environments. The product family is identified as OMNIMATE Power - series BV/SV 7.62HP, and the touch-safe protection complies with DIN VDE standards.
