Weidmuller 9456990250
M12 Connector Cable SAIL-M12GM12G-2/4-2.5U
Product Description
The M12 connector cable, designated as SAIL-M12GM12G-2/4-2.5U, is designed for sensor and actuator applications. It incorporates a 3-pole configuration with a straight pin and socket connection. The cable measures 2.5 meters in length and is made from PUR sheath material, ensuring flexibility and durability.
This cable adheres to the IEC 61076-2-101 connector standard and is rated for a voltage of 250 V and a current of up to 4 A. It features a gold-plated contact surface, enhancing conductivity. The protection degree is IP65, IP66, IP67, and IP68 when properly connected, making it suitable for various environmental conditions.
The cable's core cross-section is 0.34 mm², and it has a minimum bending radius of 5 times its diameter when stationary and 10 times when in motion. It is resistant to hydrolysis and microbes, and complies with several flame resistance standards including UL 1581 and IEC 60332. With a temperature range of -40 to +80 °C when stationary and -25 to +80 °C during movement, it can withstand demanding operational conditions.
Need more information?
Offer details
- Offer from:
Trusted supplier — Czechia, member since 2023, 100–499 employees - Availability:
- On requestLead time to be confirmed
- Warranty:
- 12 months
- Condition:
- New Factory Sealed
Specifications
- Brand
- Weidmuller
- Approvals
- CULUS
- ROHS
- Conform
- UL File Number Search
- E307231
- Connector standard
- IEC 61076-2-101
- Certificate no. (cULus)
- E307231
- AF size
- 12 mm
Available Offers
(5)| Condition | Availability | Supplier | Warranty | Action | |
|---|---|---|---|---|---|
 | Condition New Factory Sealed | Availability On requestLead time to be confirmed | SupplierCzechiaTrusted supplier — member since 2023, 100–499 employees | Warranty 12 months | |
| Condition New Factory Sealed | Availability On requestLead time to be confirmed | Supplier PolandTrusted supplier — member since 2021, 50–99 employees | Warranty 12 months | |
| Condition New Factory Sealed | Availability On requestLead time to be confirmed | Supplier LatviaTrusted supplier — member since 2024, 20–49 employees | Warranty 12 months | |
| Condition New Factory Sealed | Availability On requestLead time to be confirmed | Supplier ItalyTrusted supplier — member since 2021, 10–19 employees | Warranty 12 months | |
| Condition New Factory Sealed | Availability On requestLead time to be confirmed | Supplier GermanyTrusted supplier — member since 2023, 5–9 employees | Warranty 12 months |
Offer with manufacturer lead time
Directly from the manufacturer - with a confirmed, predictable, and fully transparent delivery time.
Documents
Data Sheet
Datasheet for Weidmuller 9456990250, including specifications and features.
CAD Models
3D CAD model and technical drawings, ready for your design software.
Product data updated: 24-04-2025
