Weidmuller 9457390500
SAIL-M12GM12W-3-5.0U
Product Description
This product is a connecting line with M12 connectors designed for sensor and actuator applications. It features a straight socket and a 90° configuration, ensuring versatile installation options. The cable is 5 meters long, constructed with a PUR sheath and includes three poles. The connection thread adheres to M12 specifications, offering a protection degree of IP65, IP66, IP67, and IP68 when properly secured.
With a rated voltage of 250 V and a rated current of 4 A, this cable is suitable for various industrial environments, functioning effectively within a temperature range of -25 to +80 °C. The construction includes a gold-plated contact surface, enhancing conductivity and reliability. It is compliant with IEC 61076-2-101 standards, with approvals including CULUS and ROHS.
The cable itself has an outer diameter of 4.3 ± 0.2 mm and features a core cross-section of 0.34 mm². It is designed for high flexibility, accommodating bending cycles of up to 2 million while being resistant to hydrolysis and microbes. The cable is also oil-resistant and adheres to various flame resistance standards, making it suitable for demanding applications.
Need more information?
Offer details
- Offer from:
Trusted supplier — Italy, member since 2021, 10–19 employees - Availability:
- On requestLead time to be confirmed
- Warranty:
- 12 months
- Condition:
- New Factory Sealed
Specifications
- Brand
- Weidmuller
- Approvals
- CULUS
- ROHS
- Conform
- UL File Number Search
- E307231
- Connector standard
- IEC 61076-2-101
- Certificate no. (cULus)
- E307231
- AF size
- 12 mm
Available Offers
(1)| Condition | Availability | Supplier | Warranty | Action | |
|---|---|---|---|---|---|
 | Condition New Factory Sealed | Availability On requestLead time to be confirmed | SupplierItalyTrusted supplier — member since 2021, 10–19 employees | Warranty 12 months |
Offer with manufacturer lead time
Directly from the manufacturer - with a confirmed, predictable, and fully transparent delivery time.
Documents
Data Sheet
Datasheet for Weidmuller 9457390500, including specifications and features.
CAD Models
3D CAD model and technical drawings, ready for your design software.
