Mersen MPDB67520
PDB UL1953 1000V 460A Adder 2 4/0-#6 in-2 4/0-#6 out Box/Box
Descripción del producto
The Power Distribution Block (PDB) facilitates safe splicing and distribution of electrical power, effectively branching primary circuits into secondary ones. This model adheres to UL508A and National Electrical Code® standards, ensuring compliance with feeder and branch circuit requirements.
Featuring dual conductor primary inputs and a maximum of 30 secondary outputs, this block enables extensive customization for varied applications. With a maximum operating temperature of 80 °C, it is suitable for diverse environments.
Constructed with virtually unbreakable glass-filled polycarbonate insulators, this block includes optional hinged safety covers that enhance safety and shock resistance without requiring tools for installation. The short circuit ratings demonstrate high resilience, reaching up to 600 kA for Class J, ensuring robust performance under fault conditions.
Additional specifications include a torque rating of 150 in-lbs for wire sizes ranging from 4/0 to #3, accommodating flexible conductors with DLO-type fine-strand wire connectors. The PDB is manufactured in Mexico and is part of the MPDB Series UL 1953 Open-Style Power Distribution Blocks.
¿Necesita más información?
- Consigue plazos de pago de hasta 90 días de 500+ proveedores.
- Descuentos de reventa de hasta el 40%!
Especificaciones
- Marca
- Mersen
- Adder Poles
- All sizes have optional adder poles for increased flexibility and ease-of-use. Adder poles can be stacked to form multi-pole units in the field without the use of tools. Adder poles allow for customization of primary and secondary wire combinations. End barriers are also available for sale, catalog numbers can be found in the catalog number selection tables for each size block.
- Wire Connectors
- Standard aluminum and copper wire connectors are available. Aluminum connectors accept both AL or CU wire while copper connectors accept CU wire only. Connectors are all 1-piece tin-plated. Many part numbers are rated to accept DLO-type fine-strand wire, allowing users to connect flexible conductors.
- Insulators
- Insulators are virtually unbreakable, made of glass-filled polycarbonate. “See-through,” hinged safety covers are optional and provide a greater degree of safety and shock resistance where required. Hinged covers can be installed without tools.
- Spacings
- 1 inch through air and 2 inches over surface between uninsulated live parts of opposite polarity meets requirements for feeder and branch circuit applications of UL508A.
- Safety Covers
- Polycarbonate safety covers provide dead-front protection. One cover is needed for each pole. Each cover has a test probe hole in the center for circuit checking. Covers are optional accessories and catalog numbers can be found in the catalog selection tables for each size block.
- Max Operating Temp
- 80 °C
