Phoenix Contact 1607860

The device connector designed for front mounting operates with a straight configuration and employs screw locking for secure attachment. It adheres to the M23 standard and accommodates 17 pin positions, utilizing a crimp connection method. This connector is equipped with an axial O-ring and features a shielded design, ensuring reliable performance in challenging environments.

With a degree of protection rated at IP67, it is suitable for use in applications that require robust sealing against dust and water. The connector can operate within a temperature range of -40 °C to 125 °C and at altitudes up to 2000 m, making it versatile for various industrial applications. The designation code RF-17P1N8AWA00 is applicable for reference.

Constructed from durable materials, the housing is made of GD-Zn with a nickel surface treatment, while the insulating body is composed of PA 6.6. The contact connection type is pin, with a nominal current rating of 8 A and a nominal voltage of 48 V AC, ensuring efficient signal transmission.
