LA1KN04

Environment

Ambient Air Temperature For Operation

-25-50 °C

Ip Degree Of Protection

IP20 conforming to IEC 60529

Ambient Air Temperature For Storage

-50-80 °C

Environmental Characteristic

normal environment

Protective Treatment

TC IEC 60068

Operating Altitude

6561.68 ft (2000 m)

Contractual warranty

Warranty

18 months

Offer Sustainability

Rohs Exemption Information

Yes

Mercury Free

Yes

Environmental Disclosure

ENVPEP2106022

Sustainable Offer Status

Green Premium product

Toxic Heavy Metal Free

Yes

Reach Regulation

Free of Substances of Very High Concern above the threshold

Reach Free Of Svhc

Yes

Weee

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

China Rohs Regulation

Pro-active China RoHS declaration (out of China RoHS legal scope)

Circularity Profile

N/A

Eu Rohs Directive

Compliant

Complementary

Permissible Short-Time Rating

80 A 1 s || 60 A 500 ms || 110 A 100 ms

Minimum Switching Current

5 mA

Height

30 mm

Non Overlap Distance

0.5 mm

Insulation Resistance

> 10 MOhm

Irms Rated Making Capacity

110 A at <= 690 V AC conforming to IEC 60947

Associated Fuse Rating

10 A gG at <= 690 V conforming to IEC 60947

Net Weight

0.045 kg

Connections - Terminals

screw clamp terminals 1 0.34-1.5 mm²flexible with cable end || screw clamp terminals 1 0.75-4 mm²flexible without cable end || screw clamp terminals 1 1.5-4 mm²rigid || screw clamp terminals 2 0.34-1.5 mm²flexible with cable end || screw clamp terminals 2 0.75-4 mm²flexible without cable end || screw clamp terminals 2 1.5-4 mm²rigid

Minimum Switching Voltage

17 V

Tightening Torque

1.3 N.m Philips No 2 || 1.3 N.m pozidriv No 2

Width

38 mm

Depth

35 mm

Specifications

Product Certifications

CB Scheme || CCC || UL || CSA || CE || UKCA

[Ith] Conventional Free Air Thermal Current

10 A (at 50 °C)

Standards

EN/IEC 60947-5-1 || UL 60947-5-1 || CSA C22.2 No 60947-5-1 || GB/T 14048.5 || JIS C8201-5-1

[Ue] Rated Operational Voltage

690 V AC 25...400 Hz

Range Compatibility

TeSys K LC1K || TeSys K CA2K || TeSys K CA3K

Product Or Component Type

auxiliary contact block

Product Name

TeSys K

Range

TeSys

Mounting Location

front

Pole Contact Composition

4 NC

[Ui] Rated Insulation Voltage

690 V IEC 60947-5-1 || 600 V UL 60947-5-1 || 600 V CSA C22.2 No 60947-5-1

Auxiliary Contacts Operation

instantaneous

Device Short Name

LA1
