Siemens 6AG1222-1XF32-2XB0

The S7-1200 SM 1222 module is designed for digital output applications, featuring 8 relay outputs with a switching capacity of 2 A. This module operates within a temperature range of -40 °C to +70 °C, making it suitable for a variety of industrial environments.

With a supply voltage range of 20.4 V to 28.8 V DC, this module is compatible with various DC voltages. The conformal coating enhances its durability, ensuring reliable performance even under challenging conditions. The design allows for simple electrical connections via screw or spring terminals, accommodating up to 500 m of shielded cable length.

In terms of diagnostics, the module includes LED indications for output statuses and supports a maximum delay time of 10 ms for signal changes. It is compliant with several industrial standards, including ATEX gas protection categories, and is capable of withstanding environmental challenges such as high humidity and exposure to various chemicals.

This module is classified under the product type designation SM 1222, based on the model 6ES7222-1XF32-0XB0, making it a key component in the S7-1200 series of digital modules.
