Weidmuller 1851080000

The male header connector is specifically designed for PCB applications with a 10.16 mm pitch and a 90° outgoing elbow, accommodating a total of 6 poles. It utilizes THT solder connections, ensuring a reliable assembly. The solder pin length measures 3.5 mm and is silver-plated to enhance conductivity.

Rated for a voltage of 600 V under specific conditions, the connector supports a maximum current of 60 A across its poles. It is tested according to IEC standards, confirming its suitability for various industrial applications. The connector also meets cURus and EAC approvals, ensuring compliance with international safety standards.

Constructed from PBT GF insulating material with a black finish, this connector exhibits a Comparative Tracking Index (CTI) of ≥ 200, and an insulation strength of ≥ 108 Ω. It operates efficiently across a temperature range of -50 °C to 120 °C, making it suitable for diverse environments. The minimum clearance and creepage distances are 8.9 mm and 10.5 mm, respectively, ensuring safe operation.

The packaging is provided in a box format with dimensions of 65 mm x 85 mm x 185 mm, facilitating convenient storage and handling. This connector is part of the OMNIMATE Power product family, ensuring compatibility with other components in the series.
