Weidmuller 1869840000

The LSF-SMT 7.62/04/180 1.5SN BK TU is a printed circuit board terminal designed for efficient connectivity. This component features a 7.62 mm pitch and accommodates 4 poles with a conductor outlet direction of 180°. The solder pins measure 1.5 mm in length, and the terminal is suitable for wire cross-sections ranging from 0.13 mm² to 1.5 mm².

Compliance with various standards ensures reliability, with a rated voltage of 300 V and a rated current of up to 12 A, depending on the application group as per UL 1059 specifications. The terminal is constructed from LCP GF material, providing durability and a flammability rating of V-0, ensuring safety in operation.

This component adheres to multiple certifications, including cURus and VDE, and is tested according to IEC standards, confirming its performance in demanding environments. Its operating temperature range spans from -50 °C to 120 °C, making it versatile for various applications.

Moreover, the LSF-SMT terminal is packaged in a tube format, facilitating easy handling and storage. The item is designed with a PUSH IN wire connection method and is compatible with solder connections, making it user-friendly for assembly on PCBs.
