Siemens
6AV2124-0UC24-0AX0
SIMATIC HMI TP1900 COMFORT PRO
- Termin płatności do 90 dni od 500+ dostawców.
- Rabaty na odsprzedaż do 40%!
€3,600.00
1
Metody płatności:
Łącznie 5 części w magazynie od 19 dostawców
Stan produktu:
Oferta z czasem realizacji przez producenta
Wysyłka:Na zapytanie
Najlepsza cena:
€3,473.96
Tak, możemy naprawić!
Współpracujemy z ponad 120 firmami naprawczymi w Europie, aby uzyskać najlepszą ofertę.
Czas realizacji:Na zapytanie
Możesz naprawić 6AV2124-0UC24-0AX0 za:
€1,818.00
Opis
AktywnyZgodny z RoHS
SIMATIC hmi tp1900 comfort pro. support arm. comfort panel. touch operation. 19 widescreen-tft-display. 16 mil. colors. PROFINET interface. mpi/PROFIBUS dp interface. 24 mb user memory. wec 2013 configurable from WinCC comfort v14 sp1 with hspAdditional Information
- Part Number
- 6AV2124-0UC24-0AX0
- UPC
- 804766495779
- Tariff Code
- 8537109170
- Country of Origin
- DE
- ETIM
- Group Code : EG000024
- Group Description : PLC's
- Class Description : Graphic panel
- Class Code : EC001412
- Version : 7
Specifications
- Country of Origin
- DE
- With recipes
- true
- Type of display
- TFT
- Built-in depth
- 101 mm
- Supply voltage DC
- 19.2 V
- Screen diagonal
- 18.5 inch
- Width of the front
- 462 mm
- With colour display
- true
- With printer output
- true
- Height of the front
- 296 mm
- Number of system buttons
- 0
- With numeric keyboard
- true
- Number of buttons with LED
- 0
- Number of password levels
- 50
- With message indication
- true
- Number of HW-interfaces USB
- 2
- Number of online languages
- 32
- Number of pixels, vertical
- 768
- Operation temperature
- 0 °C
- Number of HW-interfaces other
- 0
- Number of interfaces PROFINET
- 2
- Number of HW-interfaces RS-232
- 0
- Number of HW-interfaces RS-422
- 0
- Number of HW-interfaces RS-485
- 1
- With alpha numeric keyboard
- true
- Number of pixels, horizontal
- 1366
- Voltage type of supply voltage
- DC
- Number of HW-interfaces Wireless
- 0
- Number of HW-interfaces parallel
- 0
- Supporting protocol for MODBUS
- true
- Supporting protocol for TCP/IP
- true
- Number of HW-interfaces serial TTY
- 0
- Supporting protocol for PROFIBUS
- true
- Touch technology
- Capacitive multitouch
- Supporting protocol for EtherNet/IP
- true
- Supporting protocol for PROFINET IO
- true
- Number of colours of the display
- 16777216
- Degree of protection (IP), front side
- IP65
- Number of function buttons, programmable
- 0
- Process default value (input) possible
- true
- Useful project memory/user memory
- 24000 kByte
- Additional software components, loadable
- true
- Number of HW-interfaces industrial Ethernet
- 2
- Number of grey-scales/blue-scales of display
- 0
- Supporting protocol for other bus systems
- true
- Process value representation (output) possible
- true
- With message system (incl. buffer and confirmation)
- true
