Schneider Electric 3109140038

Name: NEMA Motor Starter, Type S, replacement coil, 110/120VAC 50/60Hz, NEMA Size 4 starters and 8903SV lighting contactors
Brand: Schneider Electric
SKU: 3109140038

NEMA Motor Starter, Type S, replacement coil, 110/120VAC 50/60Hz, NEMA Size 4 starters and 8903SV lighting contactors

1 / 5

Schneider Electric 3109140038 NEMA Motor Starter, Type S, replacement coil, 110/120VAC 50/60Hz, NEMA Size 4 starters and 8903SV lighting contactors — General Accessories

Manufacturer catalogue image

Product Description

Lifecycle Status:

The coil can be easily replaced in a Type S contactor or starter. By changing out the coil, the contactor or starter can be used in different control circuit voltage applications. This will also save the cost of a whole new contactor or starter if the coil were to fail. This coil is used in an 8502SF contactor, an 8536SF starter or an 8903SV lighting contactor. This coil is rated for 110/120 VAC 50/60 Hz. The inrush power of this coil is 1185 VA. It has an average sealed consumption of 85 VA. This coil has a height of 74.7 mm, a width of 65 mm and a depth of 62.7 mm. Coil is fully encapsulated to protect it. Coil has screw clamp connections.

Send Inquiry

Payment methods:

Offer details

Best offer from:: Trusted supplier — United States, member since 2024
Availability:: 1 pc.
On Request
Updated at: 06-09-2026
Warranty:: 12 months
Condition:: New Surplus

New Surplus - A new, unused, undamaged item without a manufacturer guarantee. The item may come without original packaging or in replacement packaging. If provided, the box may have been opened.

The Seller is responsible for shipping the product and invoicing

Specifications

Brand: Schneider Electric
Average Consumption: 89 VA || 85 VA
[Ue] Rated Operational Voltage: 120 V AC 60 Hz || 110 V AC 50 Hz
Nema Size: 4
Inrush Power In Va: 1185 VA || 1260 VA
Warranty: 18 months
Accessory / Separate Part Destination: class 8502 type SF contactor || class 8903 type SV lighting contactor || class 8910 type SYD230 contactor
