Schneider Electric
GTK03
1 / 5
Description
Active Mature
The Square D™ by Schneider Electric brand Heavy Duty Safety Switch is designed to be tough, reliable and provide exceptional performance in the most grueling conditions. F Series safety switches provide significantly higher levels of mechanical endurance than NEMA KS-1 or UL98 standards require. All heavy duty safety switches feature a quick-make, quick-break operating mechanism, a dual cover interlock and a color-coded indicator handle. This Square D heavy duty safety switch grounding bar comes in 30A and 60A. This grounding bar accepts AWG gauges of AWG 12 (CU), AWG 10 (AL), and AWG 4 (AL/CU). This product comes with an 18 month warranty. This heavy duty safety switch grounding bar by Square D has a rated current of 30A and 60A and is rated for an AWG gauge of AWG 12, copper- Country of Origin
- US
- Part Number
- GTK03
- Tariff Code
- 8536698000
- EAN
- 39121101
- UPC
- 785901421818
- UNSPSC
- 39121101
- Get up to 90 days payment terms from 500+ suppliers
- Reselling discounts up to 40%!
Send request for price
1
Payment methods:
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- China Rohs Regulation
- Product out of China RoHS scope. Substance declaration for your information.
- Circularity Profile
- N/A
- Rohs Exemption Information
- Yes
- Mercury Free
- Yes
- Environmental Disclosure
- ENVPEP1304031
- Sustainable Offer Status
- Green Premium product
- Eu Rohs Directive
- Compliant with Exemptions
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Complementary
- Height
- .437 in
- Tightening Torque
- 20-20 lbf.in (AWG 14...AWG 10) || 20-20 lbf.in (AWG 12...AWG 10) || 25-25 lbf.in (AWG 8) || 35-35 lbf.in (AWG 6...AWG 4) || 25-25 lbf.in (2 x AWG 14...2 x AWG 10) || 25-25 lbf.in (2 x AWG 10...2 x AWG 10)
- Line Rated Current
- 30 A F1 || 30 A F5 || 30 A F7 || 60 A F1 || 60 A F3 || 60 A F5 || 60 A F7
- Awg Gauge
- AWG 12 copper || AWG 10 aluminium || AWG 4 copper or aluminium
- Width
- 1.054 in
- Depth
- .312 in
Specifications
- Series Name
- heavy duty
- Range Of Product
- Square D
- Product Or Component Type
- safety switch grounding bar
