Schneider Electric LC3D32AP7

Name: TeSys Deca , star delta starter , 3 x 3P (3 NO) , 32 A , 230 V AC coil
Brand: Schneider Electric
SKU: LC3D32AP7

TeSys Deca , star delta starter , 3 x 3P (3 NO) , 32 A , 230 V AC coil

1 / 1

Manufacturer catalogue image

Product Description

Lifecycle Status:

TeSys D pre-assembled star-delta starter, for motor control applications up to 25kW@400V in delta connection. Plate mounted starter, open version, composed of 3 contactors LC1D with 230V 50/60Hz AC coils, 1NC built-in auxiliary contact on star, a time-delay contact block 1-30 sec. For operating rates until 30 starts/hour, maximum starting time 30 sec. Compact assembly (165mm width), screw fixing. Equipped with pre-wired star delta power connections, and mechanical interlock, the use of a thermal overload relay (to be ordered separately) is strongly recommended. Green Premium compliant (RoHS/REACh).

Send Inquiry

Payment methods:

Offer details

Best offer from:: Trusted supplier — Romania, member since 2023, 1–4 employees
Availability:: 1 pc.
On Request
Updated at: 22-08-2026
Condition:: New Surplus

New Surplus - A new, unused, undamaged item without a manufacturer guarantee. The item may come without original packaging or in replacement packaging. If provided, the box may have been opened.

The Seller is responsible for shipping the product and invoicing

Specifications

Brand: Schneider Electric
Mechanical Robustness: vibrations contactor open2 Gn, 5...300 Hz || vibrations contactor closed4 Gn, 5...300 Hz || shocks contactor closed15 Gn for 11 ms || shocks contactor open8 Gn for 11 ms
Ambient Air Temperature For Operation: -40-70 °C at Uc
Climatic Withstand: IACS E10 || IEC 60947-1 Annex Q category D
Pollution Degree: 3
Insulation Resistance: > 10 MOhm for signalling circuit
Flame Retardance: V1 conforming to UL 94
