Schneider Electric LV429037
trip unit TM16D for ComPact NSX 100 circuit breakers, thermal magnetic, rating 16 A, 3 poles 3d
Product Description
The TM16D trip unit is specifically designed for ComPact NSX 100 circuit breakers, featuring a thermal-magnetic operation. With a rated current of 16 A at 40 °C, it provides essential protection for distribution applications.
This unit incorporates adjustable thermal overload protection and fixed magnetic protection to guard against short-circuits. The protection type includes overload (thermal) and short-circuit (magnetic), ensuring reliability in various operational contexts. The rated operational voltage stands at 690 V AC for 50/60 Hz and 750 V DC, accommodating both AC and DC networks.
Notably, the TM16D is part of the EcoStruxure Power architecture when paired with PowerTag NSX and the Compact NSX basic frame. Its design adheres to international standards, including EN/IEC 60947-2 and UL 508, and it operates effectively within ambient temperatures ranging from -25 to 70 °C.
Offer details
- Best offer from:
Trusted supplier — United Kingdom, member since 2023- Availability:
- 5 pcs.In-StockUpdated at: 14-09-2026
- Warranty:
- 12 months
- Condition:
- New Surplus
Specifications
- Brand
- Schneider Electric
- Network Frequency
- 50/60 Hz
- Trip Unit Name
- TM-D
- Range Of Product
- ComPact NSX100...250 || ComPact NSX100...250 DC
- [Ue] Rated Operational Voltage
- 690 V AC 50/60 Hz || 750 V DC
- Trip Unit Protection Functions
- LI
- Network Type
- AC || DC
