Schneider Electric LV430770
Schneider Electric Compact NSX160F Circuit Breaker
1 / 2
Manufacturer catalogue image
Product Description
Lifecycle Status:Successor:
The Schneider Electric Compact NSX160F is a complete 3-pole circuit breaker designed to optimize space and breaking capacity. It is an ideal choice for both standard and specific applications. The breaking capacity (Icu) is 36 kA at 415 VAC 50/60 Hz, and the operational voltage is 690 VAC 50/60 Hz. This product includes an electronic MicroLogic 2.2 trip unit with a rated current of 160 A. The MicroLogic 2.2 trip unit provides adjustable long-time and short-time protections, as well as fixed instantaneous protection.
The 3-pole version (105 mm x 161 mm x 86 mm) comes with a range of optional features and accessories. It complies with international standards such as IEC 60947, CCC, EAC, and marine specifications. The Compact NSX160F is part of Schneider Electric's Ecostruxure power architecture.
Send Inquiry
Payment methods:
Offer details
- Best offer from:
Trusted supplier — Czechia, member since 2021, 50–99 employees- Availability:
- 3 pcs.In-StockUpdated at: 06-09-2026
- Warranty:
- 24 months
- Condition:
- New Factory Sealed
New Factory Sealed - A brand-new, unused, unopened, undamaged item in its original manufacturer-sealed packaging.
The Seller is responsible for shipping the product and invoicing
Specifications
- Brand
- Schneider Electric
- Product Range
- Compact NSX
- Product Name
- Compact NSX160F
- Product Type
- Circuit Breaker
- Number of Poles
- 3
- Rated Current
- 160 A at 40 °C
- Operational Voltage
- 690 VAC 50/60 Hz
