Schneider Electric LZ2H2X4FU

The reversing ultra compact starter is designed for the control and protection of three-phase motors, accommodating an operational range of up to 0.75kW at 400V. Its hybrid technology enables a compact width of just 22.5mm while ensuring an electrical durability of 30 million cycles under AC-53 conditions. The device supports adjustable motor current settings from 0.18A to 2.4A and incorporates class 10A thermal overload protection with options for manual, automatic, or electrical reset.

Additionally, the starter features safeguards against phase loss and unbalance, as well as stall and jam motor protection. It operates on a supply voltage of 110-230V AC and includes logic inputs for forward/reverse motor direction control and remote reset capabilities following thermal tripping. The fault indication is facilitated by a single C/O contact relay, with LED status indicators on the front panel to signal tripping and motor operation.

Designed for DIN rail mounting and equipped with screw terminals for both control and power connections, this starter is capable of functioning effectively in ambient temperatures ranging from -25°C to 70°C without derating. It adheres to multiple standards including IEC and UL, and is compliant with Green Premium requirements, ensuring it is free from hazardous substances.
