Siemens 3VA1163-1AA36-0AA0
MCSW 3VA11 3P 63A BOX
1 / 1
Manufacturer catalogue image
Product Description
Lifecycle Status:
The MCSW 3VA11 3P 63A BOX is a low voltage molded case switch that adheres to IEC standards, featuring a self-protecting instantaneous trip unit. It operates at a rated permanent current of 63A and is designed with a 3-pole configuration, making it suitable for various applications where reliable disconnection is essential.
This model includes a box terminal connection and a steel wrap-around lug, which enhances its installation flexibility. With dimensions of 3 x 5.1 x 3.5 inches, it is compact yet capable of handling a maximum rated operation voltage of 690V AC. The device is engineered for front mounting and offers a degree of protection rated at IP40, ensuring its suitability for various environments.
Furthermore, the switch can also function as a main switch and is compatible with motor drives, though it does not include integrated motor drive functionality. The constructed device is categorized as a built-in device with fixed installation technique, making it ideal for use as both a maintenance/service switch and an emergency stop installation.
Send Inquiry
Payment methods:
Offer details
- Best offer from:
Trusted supplier — Germany, member since 2024- Availability:
- 0 pcs.On RequestUpdated at: 04-09-2026
- Condition:
- New Factory Sealed
New Factory Sealed - A brand-new, unused, unopened, undamaged item in its original manufacturer-sealed packaging.
The Seller is responsible for shipping the product and invoicing
Specifications
- Brand
- Siemens
- Number of poles
- 3
- Interlockable
- Motor drive optional
- Version as main switch
- Motor drive integrated
- Version as safety switch
