Siemens
3VA2125-6HN36-0AA0
1 / 1
Description
Active
SIEMENS LOW VOLTAGE 3VA IEC MOLDED CASE CIRCUIT BREAKER WITH ELECTRONIC TRIP UNIT. 3VA21 FRAME WITH HIGH (CLASS H) BREAKING CAPACITY. 25A 3-POLE Icu: (2.5KAIC AT 690V) (85KAIC AT 415V). ETU350 TRIP UNIT LSI. SPECIAL FEATURES: CONNECTION WITH BOX TERMINAL / STEEL WRAP AROUND LUG. DIMENSIONS (W x H x D) IN: 4.1 x 7.1 x 4.2.- Country of Origin
- CZ
- Part Number
- 3VA2125-6HN36-0AA0
- Tariff Code
- 85362010
- EAN
- 4042948825648
- UPC
- 804766438424
Payment methods:
- Best offer from:
Trusted Automa.Net Supplier- Availability:
- 1 pc.In-StockUpdated at: 28-10-2024
- Warranty:
- 12 months
- Estimated Delivery:
- On Request
- Condition:
- New Surplus
New Surplus - A new, unused, undamaged item without a manufacturer guarantee. The item may come without original packaging or in replacement packaging. If provided, the box may have been opened.
Secure Payment Process
Return & Refund Policies
Shipping Policies
Warranty Policies
Specifications
- Country of Origin
- CZ
- Number of poles
- 3
- Rated voltage
- 690 V
- Motor drive optional
- true
- Degree of protection (IP)
- IP40
- Rated permanent current Iu
- 25 A
- Overload release current setting
- 10 A
- Type of control element
- Rocker lever
- Complete device with protection unit
- true
- DIN rail (top hat rail) mounting optional
- true
- Suitable for DIN rail (top hat rail) mounting
- true
- Adjustment range undelayed short-circuit release
- 300 A
- Number of auxiliary contacts as change-over contact
- 0
- Number of auxiliary contacts as normally open contact
- 0
- Number of auxiliary contacts as normally closed contact
- 0
- Type of electrical connection of main circuit
- Frame clamp
- Position of connection for main current circuit
- Front side
- Device construction
- Built-in device fixed built-in technique
- Rated short-circuit breaking capacity lcu at 400 V, 50 Hz
- 85 kA
