Siemens 5ST3712

The Pin Busbar measuring 1016 mm is designed to facilitate 3-phase electrical connections. With a cross-section of 16 mm², this busbar is equipped for use with various devices, specifically compatible with 5SY4 and 5SY5 supplementary protectors. Its operational current rating is 80 A, and it is suitable for interaction with devices incorporating auxiliary switches.

This busbar does not include end caps, and it can be cut to meet specific installation requirements. It features a pin type electrical connection and is insulated, ensuring a safe and reliable operation. The design incorporates three poles, with a modular width of 18 mm and a height of 15 mm. The overall weight of the unit is 570 g.

Notably, the busbar is manufactured in Germany and is not UL rated. It is designed for a one-side/center infeed with ratings of 65 A for one side and 120 A for the center. The product is identified under the designation code of the Pin busbar type, ensuring clarity in its applications.
