Wago
706-753/301-300
1 / 3
- Part Number
- 706-753/301-300
- Tariff Code
- 85444290900
- UPC
- 4050821081654
- ETIM
- Group Code : EG000026
- Group Description : Sensors
- Class Description : Sensor-actuator patch cord
- Class Code : EC001855
- Version : 7
- Get up to 90 days payment terms from 500+ suppliers
- Reselling discounts up to 40%!
Send request for price
1
Payment methods:
Environmental Requirements
- Ambient temperature (operation)
- -25 … +70 °C
Electrical Data
- Operating voltage
- ≤35 VDC
- Current per wire (max.)
- 1 A
Physical Data
- Cable length
- 3 m
Material Data
- Fire load
- 0.000 MJ
- Weight
- 9.999 g
Connection 2
- Connector 2
- Pluggable connector per DIN 41651; female connector
- Pole number 2
- 16
- Connection type 2
- System
Specifications
- Product Group Code
- 0030
Commercial Data
- Packaging type
- Box
- Country of origin
- FR
- GTIN
- 4050821081654
- Customs tariff number
- 85444290900
Notes
- Note
- When using more than 10 wires, the maximum current per wire must be reduced to 0.7 A.
Connection 1
- Connector
- Pluggable connector per DIN 41651; female connector
- Pole number 1
- 16
- Connection type 1
- System
- Wire cross-section
- 0.14 mm²
- Connection type
- Pluggable Connector per DIN 41651
