Weidmuller 1813390000
10.16mm Male PCB Plug-In Connector, 8 Poles, 90°
Product Description
This male PCB plug-in connector features a closed side design with a 90° outgoing elbow and is suitable for THT solder connections. With a pitch of 10.16 mm and a solder pin length of 3.5 mm, it accommodates up to 8 poles, each with three solder pins. The connector is constructed from PBT GF insulating material and is finished in black, complying with RAL 9011.
Rated for a maximum voltage of 600 V and a current up to 60 A depending on the use group, this component meets various international standards including IEC 60664-1 and IEC 61984. The connector also ensures high reliability with a minimum clearance distance of 8.9 mm and a creepage distance of 10.5 mm.
Additional features include a Comparative Tracking Index (CTI) of ≥ 200 and an insulation strength of ≥ 108 Ω. It is rated V-0 according to UL 94 for flammability and can operate within a temperature range of -50 °C to 120 °C, making it suitable for a variety of applications. The packaging is provided in a box with dimensions of 65 mm x 85 mm x 190 mm.
Need more information?
Offer details
- Offer from:
- Trusted supplier — Czechia, member since 2023, 100–499 employees
- Availability:
- On requestLead time to be confirmed
- Warranty:
- 12 months
- Condition:
- New Factory Sealed
Specifications
- Brand
- Weidmuller
- Institute (cURus)
- cURus
- Certificate No. (cURus)
- E60693
- Rated voltage (Use group B / UL 1059)
- 300 V
- Rated voltage (Use group C / UL 1059)
- 300 V
- Rated voltage (Use group D / UL 1059)
- 600 V
- Rated current (Use group B / UL 1059)
- 60 A
