Weidmuller 1825960000

The LSF-SMT 5.00/02/180 3.5SN BK TU is a precision-engineered printed circuit board terminal designed for reliable connectivity in electronic applications. With a pitch of 5.00 mm and a 180° conductor outlet direction, it accommodates two poles effectively. The terminal includes a solder pin length of 3.5 mm, optimized for various PCB mounting methods, including THT and THR solder connections.

This terminal supports a maximum clamping range of 1.5 mm², making it compatible with wire cross-sections ranging from AWG 28 to AWG 14. It is constructed from high-quality materials, featuring a black insulating material of LCP GF and a copper alloy contact material. The product exhibits excellent insulation strength of ≥ 108 Ω and a Comparative Tracking Index (CTI) of ≥ 175, ensuring robust performance in demanding environments.

Rated for a voltage of 300 V under UL 1059 standards and with a rated current of 12 A for Use group B, this terminal is suitable for various industrial applications. Additionally, it has been tested according to IEC standards, confirming its reliability with a rated impulse voltage of 4 kV. The terminal's dimensions are compact, with a width of 9.2 mm and a height of 17.5 mm, facilitating space-efficient designs.

It is packaged in a tube for convenient handling and storage, and the product complies with multiple certifications, including CSA and cURus. The designation code for this terminal is included for easy reference in application documentation.
