Weidmuller 2551900000

The RJ45M R12D 3.2N4G/Y RL is a specialized PCB plug-in connector, suitable for 10/100 MBit/s applications. It features a 90° outgoing elbow and is designed for THT/THR solder connections, ensuring stable and secure attachment to the PCB. The connector is equipped with eight poles and supports a maximum rated current of 1.5 A and a rated voltage of 125 V AC, making it appropriate for various networking applications.

Constructed from high-quality materials, the insulating material is PA 9T, with a black color corresponding to RAL 9011. The connector's contact base is made of phosphorus bronze with a gold over nickel contact surface, featuring a layer structure of 30-80 µ" Ni / 30- µ" Au. The device is rated for an operational temperature range of -40 °C to 85 °C and has a storage temperature range of the same extent, ensuring versatility in diverse environments.

The RJ45M connector also includes dual LEDs, with the left LED in green and the right LED in yellow, providing visual feedback during operation. With a protection degree of IP20 and a lifespan of up to 750 plugging cycles, this connector is a reliable choice for industrial applications. The product is compliant with various environmental standards, including REACH and RoHS, ensuring it meets industry regulations.
