Weidmuller 9457340750

This product is a M12 to M12 connecting line, designed with 5 poles and a length of 7.5 meters. The connection features a pin straight to socket straight configuration, adhering to the connector standard IEC 61076-2-101. The housing material is made of PUR, providing a temperature range from -25 to +80 °C, and is rated for a voltage of 125 V and a current of 4 A. It has a protection degree of IP65, IP66, IP67, and IP68 when properly screwed in.

The cable's core cross-section is 0.34 mm², with an outside diameter of 5 ± 0.2 mm. It is not shielded and has a black sheath, also made from PUR, which is halogen-free. Designed for durability, it is resistant to hydrolysis and microbes, with a bending radius of a minimum of 5 times the cable diameter when stationary and 10 times when in motion. The cable can withstand bending cycles of up to 2 million and is suitable for cable carriers, demonstrating exceptional torsion resistance of 360°/m.

Environmental compliance is achieved with REACH SVHC regulations, specifically regarding lead (7439-92-1), and it conforms to various approvals including cULus. The product features gold-plated contact surfaces and has significant operational endurance with a minimum of 100 plugging cycles and a pollution severity rating of 3.
