IFM I7R203
IFM Inductive Ring Sensor I7R203
1 / 4
Manufacturer catalogue image
Manufacturer catalogue image
Manufacturer catalogue image
Product Description
The IFM Inductive Ring Sensor I7R203 is designed for precise and rapid detection of metallic objects within its sensing range. This sensor features a dynamic operating principle, ensuring high-resolution detection with a minimal response time of less than 0.2 ms. Its robust construction includes a PA housing and POM ring, making it highly resistant to contamination and suitable for demanding industrial environments.
The I7R203 offers selectable output functions (normally open/closed) and is equipped with PNP electrical design. It operates within a voltage range of 10 to 35 V DC and includes essential protections such as reverse polarity, short-circuit, and overload protection. The sensor's high protection class of IP67 ensures reliable performance in harsh conditions.
Applications for the I7R203 include monitoring and controlling processes in automation systems, where high-speed and accurate detection of small metallic parts is crucial. The sensor's adjustable pulse stretching time and high-speed part detection capability (up to 35 m/s) make it an ideal choice for various industrial applications.
Send Inquiry
Payment methods:
Offer details
- Best offer from:
- Trusted supplier — Germany, member since 2024
- Availability:
- 1 pc.In-StockUpdated at: 05-09-2026
- Warranty:
- 12 months
- Condition:
- New Surplus
New Surplus - A new, unused, undamaged item without a manufacturer guarantee. The item may come without original packaging or in replacement packaging. If provided, the box may have been opened.
The Seller is responsible for shipping the product and invoicing
Specifications
- Brand
- IFM
- Operating voltage
- 10...35 V DC
- Current consumption
- < 20 mA
- Protection class
- III
- Reverse polarity protection
- Yes
- Electrical design
- PNP
- Output function
- Normally open / Normally closed (selectable)
