Mitsubishi FR-D740-160-EC

The Mitsubishi FR-D740-160-EC Variable Speed Drive (VSD) from the renowned FREQROL FR-D700 series is designed to deliver precise motor control and enhanced operational efficiency. This inverter supports a wide range of functions including soft-PWM control, high carrier frequency PWM control, and automatic restart after power failure. It is equipped with multiple protection features such as overcurrent, overvoltage, and thermal protection for both the inverter and motor.

With a robust design adhering to EU specifications, the FR-D740-160-EC ensures reliable performance in demanding industrial environments. It supports a 3-phase input voltage range of 380Vac to 480Vac and delivers a rated power of 7.5kW (10HP) with a rated current of 16A. The drive offers versatile control options including multi-speed operation, PID control, and computer link operation via RS-485.

Additional features include optimum excitation control, speed smoothing control, and offline auto tuning. The FR-D740-160-EC is equipped with both digital and analog inputs/outputs, providing flexible integration into various systems. It complies with EN ISO 13849-1 Category 3, EN62061, IEC61508 SIL2, and PLd standards, ensuring high safety and reliability.

Applications for this VSD include transfer systems, lifts, packaging machinery, machine tools, air conditioning systems, fans, and pumps. The FR-D740-160-EC is an ideal choice for industries seeking efficient and reliable motor control solutions.
