Siemens 3VA2163-7HK32-0AA0
3VA21 3P 63A 110KA ETU340 ELISA Circuit Breaker
1 / 1
Manufacturer catalogue image
Product Description
Lifecycle Status:
The 3VA21 3P 63A 110KA ETU340 ELISA is a low voltage molded case circuit breaker designed to meet the IEC standards. It operates with a very high breaking capacity classified as Class C, accommodating a rated current of 63A. It is capable of handling short-circuit breaking capacities of 110kA at 415V and 2.5kA at 690V.
This device includes an ETU340 electronic trip unit and is configured for line protection. The circuit breaker is equipped with a nut keeper for enhanced connectivity, utilizing screw connections for the main circuit. Its dimensions measure 4.1 x 7.1 x 4.2 inches, and it offers optional motor drive capabilities.
With an IP40 degree of protection, the device is suitable for various applications where environmental exposure is a consideration. The configuration allows for DIN rail mounting, providing versatility in installation. Additionally, the breaker is designed with no integrated earth fault protection, emphasizing its specific application in overload and short-circuit protection.
Send Inquiry
Payment methods:
Offer details
- Best offer from:
Trusted supplier — Germany, member since 2024- Availability:
- 0 pcs.On RequestUpdated at: 02-09-2026
- Condition:
- New Factory Sealed
New Factory Sealed - A brand-new, unused, unopened, undamaged item in its original manufacturer-sealed packaging.
The Seller is responsible for shipping the product and invoicing
Specifications
- Brand
- Siemens
- Number of poles
- 3
- Rated voltage
- 690 V
- Motor drive optional
- Motor drive integrated
- Degree of protection (IP)
- IP40
- Rated permanent current Iu
- 63 A
Available Offers
(2)Access our platform to find more offers
Register now to explore 36 mln offers from verified suppliers worldwide.
- Compare offers globally
- Direct supplier contact
- RFQs, Quotes, and Orders
- BOM Search
Sign UpFree 14-day trial available
Offer with manufacturer lead time
Directly from the manufacturer - with a confirmed, predictable, and fully transparent delivery time.
Documents
Data Sheet
Datasheet for Siemens 3VA2163-7HK32-0AA0, including specifications and features.
Download Data Sheet
TracePartsCAD Models
3D CAD model and technical drawings, ready for your design software.
Download CAD Model
